XFX Mercury AMD Radeon RX 9060 XT OC Gaming Edition 16GB - RX-96TMERCB9 video card
- Video chipset
- AMD Radeon
- Graphics processor
- RX 9060 XT
- Memory volume (VRAM)
- 16 GB
- Memory type
- GDDR6

Description
The XFX Mercury AMD Radeon RX 9060 XT OC Gaming Edition 16GB graphics card is aimed at mid-range to high-end gaming configurations where you want a modern GPU on the RDNA4 architecture with a focus on efficiency and high resolution. You get 16 GB GDDR6 VRAM, which is a comfortable amount for modern AAA titles, heavy textures, and a longer lifespan for the card without rapid obsolescence. The 128-bit bus and 20 Gbps memory frequency indicate an orientation toward high bandwidth at lower power consumption and temperature. The PCI Express 5.0 interface prepares it for new generations of platforms without stopping you from using newer motherboards.
What you get is a GPU on a 5 nm process with good energy efficiency, which allows for lower temperatures and more stable boost under load with active cooling. 16 GB VRAM GDDR6 gives you peace of mind for games at high detail settings and work with heavier graphical tasks – video, 3D, mods, and texture packs. With a maximum resolution of 7680x4320, you can drive an 8K display for multimedia or specific applications, and support for up to 3 simultaneous displays is sufficient for a typical gaming + work setup (main monitor, second for chat/browser, and possibly a TV). A single 8-pin connector and a recommended power supply of 450W mean that the card is not overly demanding on the PSU and is convenient for upgrading older, but still adequate, configurations.
- Graphics processor AMD Radeon RX 9060 XT on the RDNA4 architecture, aimed at modern gaming and good energy efficiency.
- 16 GB GDDR6 VRAM with a 128-bit bus provides a sufficient buffer for high details, large textures, and a longer lifespan for the card.
- Memory with a frequency of 20 Gbps, which helps with high bandwidth and stable performance at higher resolutions.
- PCI Express 5.0 interface, ready for current and future motherboards, without limiting the card's potential.
- Support for up to 7680x4320 resolution and 3 displays, suitable for multi-monitor gaming, work, and streaming.
- Video outputs with 2 x DisplayPort and 1 x HDMI, covering typical gamer and work configurations with modern monitors.
- Active cooling and only 1 x 8-pin additional power, with a recommended PSU of 450W, making the card accessible for many existing systems.
- Support for OpenGL 4.6 for compatibility with a wide range of games and professional applications.
This XFX Mercury RX 9060 XT OC is suitable for gamers aiming for stable 1080p and 1440p gaming with high details, as well as for people working with heavier graphical tasks, but not in the extreme professional class. It is also suitable for upgrading an older build where the power supply and case are more limited, thanks to the 2-slot design and 8-pin power. If you are chasing maximum high-end with extremely high refresh rates in 4K, you might want a higher class, but for balanced gaming and productivity, this card is a logical choice.
The combination of RDNA4 architecture, 16 GB GDDR6, and PCIe 5.0 makes this model very sensible for a long-term build that you will not replace after a year or two. The strongest point here is the balance between modern features, consumption, and power supply requirements – a good foundation for serious gaming without unnecessary compromises.
Full specifications
- Manufacturer
-
XFX
- Product code
- RX-96TMERCB9
- Video chipset
- AMD Radeon
- Graphics processor
- RX 9060 XT
- Architecture
- RDNA4
- Memory volume (VRAM)
- 16 GB
- Memory type
- GDDR6
- Bus width
- 128 bit
- Core speed (MHz)
- Boost: 3320 MHz
- Memory speed
- 20 Gbps
- Processor technology
- 5 nm
- Interface
- PCI Express 5.0
- Number of slots
- 2
- Display Port (DP)
- 2
- HDMI
- 1
- Max. Resolution
- 7680x4320
- Multi Display
- 3
- OpenGL
-
4.6
- Cooling
- Active
- Additional power supply
- 1 x 8 pin
- Recommended power supply
- 450W
- Card type
-
Gaming
- Size
- 320 x 127 x 53 mm
- Length (mm)
- 320
- Warranty
- 36 months
- Render Output Units Quantity (ROP)
- 64
- Texture Mapping Unit Quantity
- 128
