Производител | Gigabyte |
Продуктов код | B650 GAMING X AX |
CPU сокет | AM5 |
Чипсет | AMD B650 |
Форм фактор | ATX |
Поддържани процесори | Supports AMD Ryzen 7000 Series Desktop Processors Socket AM5 |
Поддържана памет | DDR5 |
Брой слотове за памет | 4 |
Максимален капацитет RAM памет | 128 GB |
Честота памет (MHz) | до 6400MHz (OC) |
Поддръжка на двуканална памет | Да |
Вградено аудио | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel |
Вграден LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Вграден Wi-Fi | WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate |
Интерфейс SATA | 4 x SATA3 6.0 Gb/s |
Поддръжка на RAID | 0,1,10 |
М2 слот | 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU, M2B_CPU) 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB) |
Bluetooth версия | Bluetooth V5.3 |
Разширителни слотове | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2) |
Конектор захранване | 1 x 24-pin 1 x 8-pin 1 x 4-pin |
USB портове | 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 1 x USB 3.2 Gen 1 port on the back panel 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports available through the internal USB headers |
Заден I/O панел | 2 x SMA antenna connectors (2T2R) 1 x Q-Flash Plus button 1 x DisplayPort 1 x HDMI port 1 x USB Type-C® port, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) 3 x USB 3.2 Gen 1 ports 3 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
Графика | 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version and HDR. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports. |
Bios | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
OS | Microsoft Windows 10, Microsoft Windows 11 |
Поколение процесор | 7-мо поколение |
Гаранция | 36 месеца |
